Concentric In-Line

Description
‍

Concentric In-Line Diaphragm Valve for High-Purity Processing

The Aquasyn Concentric In-Line Diaphragm Valve is designed for precise, sterile fluid control in biopharmaceutical, biotech and cleanroom manufacturing environments. Engineered from 316L stainless steel with an ASME-BPE compliant body, the valve provides a clean, crevice-free flow path, minimal dead-leg geometry and consistent diaphragm sealing for high-purity applications.

Its concentric in-line configuration supports smooth, unobstructed flow and predictable pressure drop across upstream and downstream processes. The compact body and hygienic construction make it suitable for media prep, buffer handling, sampling points, chromatography skids, filtration systems and general utility service where aseptic shutoff and controlled fluid direction are required.

The valve is available in multiple sizes, connection styles and surface finishes to integrate easily into stainless process lines, modular skids and high-purity distribution systems.
